Just an interesting article on the history of the Ethernet

Today’s entry isn’t someone else’s code, which I haven’t used for a few days. Today all I have is an article by Steven Vaughan-Nichols titled

The birth and rise of Ethernet: A History

I am not as much interested in the ubiquitous Ethernet as in its fascinating history. This is a most interesting telling of the rich history of the network and its inventor, by Vaughan-Nichols is well worth a read, not only for those interested in Ethernet itself, but also those interested in all networking, and most people using computers today, as nearly all LANs are Ethernet at present.



Using DI, Logging, and Configuration in a .NET Core Console App

Yesterday set about building a small, Core Console Application that does some data access. A very early challenge for me was how to store my connection string. I’m used to ASP.NET Core work, where the configuration is set up in the Startup class, but a plain old console app starts out none of that sweet infrastructure.

I set about frenzied Googling for anything, and it was a good day for me because I found Chad Ramos‘ article titled:

Dependency Injection, Logging and Configuration In A .NET Core Console Application

It is a very simple, three-step tutorial, very readable and with a single, code example used across all three steps. Chad includes a link to a very readable and neat example if you want more than his code excerpts in the article. It may be easier to just use his code as a startup template for such projects.

It has one small problem in that you can’t e.g. reference a class and call a method from another project because the startup code won’t have run, but this is very rare with console apps.

I am so impressed I’m going to make a project template for Core console apps ready to go, with DI, Configuration, and Logging.



Android apps in BASIC? A New IDE Using BASIC for Coding Mobile Apps

I could hardly believe it yesterday when a client, who had been struggling to get Android Studio behaving nicely for days, told me he had found an IDE called B4A, and “was able to get a prototype up and running in 2 hours”. The vendor, Anywhere Software, claim that B4A “is used by tens of thousands of developers from all over the world, including companies such as NASA, HP, IBM and others”.

Platforms supported by their B4X suite supports quite a number of platforms, including Android, iOS, Windows, Mac, Linux, Arduino, Raspberry Pi, and more, and it has a nice, familiar look for Visual Studio users:

B4X IDE with an Android app
B4X IDE











My client, more used to older VB than C# or Java, said it’s the best $59 he’ll ever spend, and is now hard at work coding Android apps in BASIC instead of fighting with Android Studio.

Of course this gives more people the means to code their own apps, instead of hiring me, but at least I know Visual Basic very well if they want it written for them.

Angular 2 Tutorial: Lots of New Topics and Updated Code

In my first Angular 2 Tutorial post, I described how I followed the QuickStart tutorial at Angular, and build on an ASP.NET Core project to match it. I have advanced quite a bit, moving on to the Tour of Heroes tutorial. In doing so, I have covered quiet a few new aspects of Angular 2.

Ending on the Master/Detail chapter of the tutorial, I had covered Displaying Data, Forms, Template Syntax, and User Input.

If you’re interested in using Angular 2 in an ASP.NET Core project, I advise you to closely follow the official tutorial, while at the same time having a look at my project for it, on GitHub.

Angular also have a bunch of other resources for learning Angular 2.

Static Files in ASP.NET Core

An ASP.NET Core Web Application is very strict about only serving resources from its Web Root, which is normally <website-root>/wwwroot. This is to prevent files that could help attackers compromise your site from being served. When you build, you use a tool like Gulp, any other, or just copy and paste, to move all files that must be served into wwwroot. Just to keep things even tighter, by default, no static files will be served from this folder.

To allow your app to serve static files from its Web Root, you must install the Microsoft.AspNetCore.StaticFiles package. You can do this using NuGet, or in the nice new way that .NET Core allows: just add the line "Microsoft.AspNetCore.StaticFiles": "1.0.0" to the dependencies object in your project.json file. As soon as you save that file, Visual Studio will automatically download and install the package. Some more magic: if you don’t just copy and paste that line into project.json, after you type the package name and colon, when you type the opening double-quote for the version, the editor will give you Intellisense for which versions are available. Normally you would just choose the latest.

After adding the StaticFiles package, you need to add the following two lines to the Configure method of your project’s Startup.cs class:

app.UseDefaultFiles();
app.UseStaticFiles();

The first line means that Kestrel will look for default files, like default.html and index.html, in the Web Root folder, and automatically serve them if no other page is requested in the URL. For some mysterious reason, this line must always be placed before the static files line.

You can change which directory static files may be served from, but, for what I think was a very bad design decision, the application can always serve static files from one directory only. Maybe one day we’ll find out why.

Now if you have used any npm packages in your project, they are installed into a folder called node_modules. After adding just a few modules, this folder can become full. On a simple little Hello world type project with Angular 2, my node_modules folder contains 16,847 files, and takes up 107MB of disk space. Node.js, what is your story, coming in and making tiny, thin .NET projects obese?

The problem with npm is that all the JavaScript files that you must add to your web pages reside somewhere in node_modules, and they won’t be served, because the app is only serving static files from wwwroot. To remedy this, I had ended up with my Configure method looking like this:

public void Configure(IApplicationBuilder app, IHostingEnvironment env, ILoggerFactory loggerFactory)
{
    app.UseDefaultFiles();
    app.UseStaticFiles();
    app.UseFileServer();
    var provider = new PhysicalFileProvider(Path.Combine(env.ContentRootPath, "node_modules"));
    var options = new FileServerOptions();
    options.RequestPath = "/node_modules";
    options.StaticFileOptions.FileProvider = provider;
    options.EnableDirectoryBrowsing = true;
    app.UseFileServer(options);

    loggerFactory.AddConsole();
    if (env.IsDevelopment())
    {
        app.UseDeveloperExceptionPage();
    }
}

I have since found out that UseFileServer() incorporates the functionality in those two lines in my first code block, so I am investigating removing them and only using UseFileServer(), but for now my app works as is, and I will only update this post after some thorough testing.

The Promised ReadMe File for the Angular 2 Tutorial Project

In yesterday’s post I described a little project where I had integrated the Angular 2 QuickStart tutorial from Angular, into an ASP.NET Core web application. I also promised to add a missing readme file to the project to help developers understand how I “merged” the two.

This is cutting edge stuff, but the first step is very simple and aimed at beginners. Yet with new tech, we are all always a beginner at something.

So, the code is on GitHub, over here: https://github.com/erisiasoft/Angular2Tutorials

Angular 2 QuickStart Tutorial Code in an ASP.NET Core Application.

tl;dr: The code is here. The tutorial is there.

Discontinued: This would-be series of articles on Angular 2 has been discontinued This is in favour of a soon to begin alternative series of dotnet based tutorials for Angular 4.

I can’t learn Angular 2 fast enough for my intuition that it will be a lot bigger than Angular 1. There are billions of examples and tutorials out there, most of them inaccurate and contradictory. Not to mention hopelessly out of date with the pace ASP.NET Core has been released at. I decided to stick to the official documentation at Angular first, which is available in TypeScript, JavaScript, and Dart language flavours.  I chose TypeScript because I want to learn it, and both Microsoft and Angular are heavily behind it. It should go places, plus it’s very sweet to use.

The docs start with a tutorial called QUICKSTART, which is a little too minimal, but enough to get started. The classic Hello World pattern. They do build on this in the next tutorial though, Tour of Heroes.

The tutorials, however, are bare minimum sets of files, in effect only the files you would deploy to your web server, and not in a project format for any IDE. QuickStart introduces four core files that nearly all Angular 2 apps need, and I thought it would be interesting, and quite easy, to create a .NET Core Web Application, and just copy those files into the application. About 5 hours later, I had my Hello World working, displaying a sentence on the screen.

There were a few version incompatibilities between frameworks and platforms included in the .NET app, a few other nigglies, but the biggest problem is that, by default, a .NET Core web app will only serve resources its wwwroot folder, and then it will still not serve any static file at all, even from that folder. Request any static file and you get an HTTP  404.

To set this right, I had to add the Microsoft.AspNetCore.StaticFiles package to the project, and add a few lines in Startup.cs. For now, just create a new, empty .NET Core web app, and compare its Startup.cs to mine.

This post is not about the all the little changes I made to get Angular 2 working in the .NET app, but it is to tell you that project is on GitHub if you want to play with Angular 2 in a .NET Core web app, but couldn’t be arsed to spend the time squeezing Angular into Core. The app is available at https://github.com/erisiasoft/Angular2Tutorials, and is a tad untidy, but the important part is the HTML and TypeScript (and JavaScript, if you want) stuff is working, so if you stick to messing about with the TypeScript classes in the app folder, and HTML files in the wwwroot folder, you too can get started on the beginner level Angular 2 tutorials.

This project is not documented yet, so please leave a comment or email me at info@erisia.com if you have any questions. I will post an overview readme as soon as I have found it again, later tonight.

In my next post I will detail the process of fitting Angular 2 to a .NET Core web app, and may proceed onto writing about the Tour of Heroes tutorial, which actually has a proper GUI that does things.





DLL Hell returns: EF Core (EF 7) scaffolding is broken by version mismatches.

I have spent the last several hours trying to use EF Core’s CLI scaffolding to reverse engineer (or scaffold) a small database into entity classes. First, it simply does not support scaffolding into a Core (or any) class library. Scaffolding is done with a command much like the following one.

dotnet ef dbcontext scaffold "data source=(local);initial catalog=HawkHead;integrated security=SSPI;multipleActiveResultSets=True" "Microsoft.EntityFrameworkCore.SqlServer" -c HhDbContext -o Data

Executing this on a class library results in an error that simply tells you that scaffolding to class libraries is not supported. One would think a quick and easy workaround would be to create a .NET Core Console Application, but then executing the above command results in any number of intractable exceptions. The most understandable one was that “Microsoft.EntityFrameworkCore.SqlServer.Design”: “1.0.1” was not compatible with “Microsoft.EntityFrameworkCore.Tools”: “1.0.0-preview2-final”. There is no higher version for “Tools”, despite MS bragging that Core was now RTM and will save the fucking world.

There is, however, a very simple workaround. Add an old fashioned .NET 4.6 Console Application to your solution, add EF 6 to it, use EF 6 to do your scaffolding, and because the entity classes are POCOs, you can just copy and paste them all into your new, trendy .NET Core class library, and they work just the same with EF Core (EF 7).

Erisia Software has a New Home.

This site will feature case studies of Erisia Software in delivering top quality information solutions, as well as news on information technology in general, and some educational material on software development. For now, this blog will concentrate of Angular 2 and .NET Core.

But right now, my clients are much more important than my website, so content will slowly begin to appear over the next week or two, and then later more regularly.
